THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
REV.
B
C
DESCRIPTION
RoHS Compliancy
Updated Specifications
REVISION
DATE
06-01-06
10-28-09
APPROVED
DP
LY
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
PHYSICAL DIMENSIONS:
ELECTRICAL CHARACTERISTICS:
1-1. VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC..........................................10 A RMS MAX
B. @ 250 VAC.........................................8 A RMS MAX
?0.188
1-3.
1-4.
1-5.
1-6.
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.50 mA MAX
B. @ 250 VAC 50Hz.............................1.00 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
2.94 ± 0.02
3.34MAX
3.75MAX
FREQ. MHz
COM. MODE dB
DIF. MODE dB
.01
2
0
.05
8
1
.10
12
20
.15
15
25
.50
20
50
1.0
30
50
5.0
60
45
10
55
45
30
45
45
1-7.
1-8.
1-9.
OPERATING TEMPERATURE.................-25° TO +85° C
SAFETY:
RoHS COMPLIANT
CONTROLLED
850-10/003
SCHEMATIC:
Dim
range
(mm)
Tolerance
+/-
(mm)
Qualtek Electronics Corp.
PPC DIVISION
Part Number:
L1:
L2:
1.2mH
40.0uH
0-1
1-6
0.15
0.20
Description:
EMI FILTER
C1:
C2:
R:
0.22uF
3300pF
330K ?
6-18
18-50
50-120
120-250
250-500
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B.ZHANG
02-11-03
UNIT: in
Checked / Date
02-11-03
REV. C
Approved / Date
JJH / 02-11-03
